JTEKT TOYODA Machine Tools

X-Axis 800mm (+300_ATC Stroke)
Y-Axis 850mm
Z-Axis 1050mm
C-Axis -210°~+20°
Table Dimensions (pallet dimensions) 630mm x 630mm

X-Axis 2,400mm
Y-Axis 1,500mm
Z-Axis 1,850mm
Table 1,250mm (Pallet)

GE4i-100 INTER
Swing Over Table Ø 12.6" (320 mm)
Workpiece Length 39.4” (1,000 mm)
Machining I.D. Ø 5.9" (150 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)

GE4i-150 INTER
Swing Over Table Ø 12.6" (320 mm) [Optional 15.75" (400 mm)]
Workpiece Length 59.0" (1,500 mm)
Machining I.D. Ø 5.9" (150 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)

GE4i-200 INTER
Swing Over Table Ø 12.6" (320 mm)
Workpiece Length 78.7" (2,000 mm)
Machining I.D. Ø 5.9" (150 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)

GE4i-50 INTER
Swing Over Table Ø 12.6" (320 mm) [Optional 15.75" (400 mm)]
Workpiece Length 19.6" (500 mm)
Machining I.D. Ø 5.9" (150 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)

GE4i-100 SWITCH
Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 39.4" (1,000 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed 8,500 (45) SFPM (m/s)

GE4i-150 SWITCH
Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 59.0" (1,500 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed 8,500 (45) SFPM (m/s)

GE4i-200 SWITCH
Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 78.7" (2,000 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed 8,500 (45) SFPM (m/s)

GE4i-50 SWITCH
Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 19.69" (500 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed 8,500 (45) SFPM (m/s)

SelectG7-100
Swing Over Table         Ø 25.9" (660 mm)
Distance Between Centers 157.4" (1,000 mm)
Grinding Diameter (Max) 25.5 (650) in (mm)
Wheel Surface Speed 6,500 (30) SFPM (m/s)

SelectG7-250
Swing Over Table Ø 25.9" (660 mm)
Distance Between Centers 98.4" (2,500 mm)
Grinding Diameter (Max) 25.5 (650) in (mm)
Wheel Surface Speed 6,500 (30) SFPM (m/s)

SelectG7-320
Swing Over Table Ø 25.9" (660 mm)
Distance Between Centers 125.9" (3,200 mm)
Grinding Diameter (Max) 25.5 (650) in (mm)
Wheel Surface Speed 6,500 (30) SFPM (m/s)

SelectG7-400
Swing Over Table Ø 25.9" (660 mm)
Distance Between Centers 157.4" (4,000 mm)
Grinding Diameter (Max) 25.5 (650) in (mm)
Wheel Surface Speed 6,500 (30) SFPM (m/s)

Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 12.6" (320 mm)
Grinding Diameter (Max) OD: 8.6 (220) ID: 4.7 (120) in (mm)
Wheel Surface Speed 8,850 (45) SFPM (m/s)

Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 24.8" (630 mm)
Grinding Diameter (Max) OD: 8.6 (220) ID: 4.7 (120) in (mm)
Wheel Surface Speed 8,850 (45) SFPM (m/s)

GE6i-100
Swing Over Table Ø 22.0" (560 mm)
Distance Between Centers 39.0" (1,000 mm)
Optional Wheel Surface Speed 8,500 SFPM (43 m/s)
Grinding Diameter (Max) 21.6 (550) in (mm)
Wheel Surface Speed 6,500 (30) SFPM (m/s)

GE6i-160
Swing Over Table Ø 22.0" (560 mm)
Distance Between Centers 63.0" (1,600 mm)
Optional Wheel Surface Speed 8,500 SFPM (43 m/s)
Grinding Diameter (Max) 21.6 (550) in (mm)
Wheel Surface Speed 6,500 (30) SFPM (m/s)

GE6i-250
Swing Over Table Ø 22.0" (560 mm)
Distance Between Centers 98.4" (2,500 mm)
Optional Wheel Surface Speed 8,500 SFPM (43 m/s)
Grinding Diameter (Max) 21.6 (550) in (mm)
Wheel Surface Speed 6,500 (30) SFPM (m/s)

GE6i-320
Swing Over Table Ø 22.0" (560 mm)
Distance Between Centers 125.9" (3,200 mm)
Optional Wheel Surface Speed 8,500 SFPM (43 m/s)
Grinding Diameter (Max) 21.6 (550) in (mm)
Wheel Surface Speed 6,500 (30) SFPM (m/s)

GE6i-400
Swing Over Table Ø 22.0" (560 mm)
Distance Between Centers 157.4" (4,000 mm)
Optional Wheel Surface Speed 8,500 SFPM (43 m/s)
Grinding Diameter (Max) 21.6 (550) in (mm)
Wheel Surface Speed 6,500 (30) SFPM (m/s)

GL5i-32
Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 12.6" (320 mm)
Grinding Diameter (Max) 8.6 (220) in (mm)
Wheel Surface Speed 11,800 (60) SFPM (m/s)

GL5i-63
Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 24.8" (630 mm)
Grinding Diameter (Max) 8.6 (220) in (mm)
Wheel Surface Speed 11,800 (60) SFPM (m/s)

GL5i-100
Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 39.4" (1,000 mm)
Grinding Diameter (Max) 8.6 (220) in (mm)
Wheel Surface Speed 11,800 (60) SFPM (m/s)

GL5i-150
Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 59.0" (1,500 mm)
Grinding Diameter (Max) 8.6 (220) in (mm)
Wheel Surface Speed 11,800 (60) SFPM (m/s)

GL7-63
Swing Over Table Ø 15.7" (400 mm)
Optional Swing Ø 19.7" (500 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed 8,860 (45) SFPM (m/s)

GL7-100
Swing Over Table Ø 15.7" (400 mm)
Distance Between Centers 39.4" (1,000 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed 8,860 (45) SFPM (m/s)

GL7-160
Swing Over Table Ø 15.7" (400 mm)
Distance Between Centers 63" (1,600 mm)
Grinding Diameter (Max) 11.8 (300) Optional 15.7 (400) in (mm)
Wheel Surface Speed 8,860 (45) SFPM (m/s)

GL7-250
Swing Over Table Ø 15.7" (400 mm)
Distance Between Centers 98.4" (2,500 mm)
Grinding Diameter (Max) 11.8 (300) Optional 15.7 (400) in (mm)
Wheel Surface Speed 8,860 (45) SFPM (m/s)

Swing Over Table Ø 15.7" (400 mm)
Distance Between Centers 12.6" (320 mm)
Optional Wheel Surface Speed 11,800 SFPM (60 m/s)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed 8,860 (45) SFPM (m/s

Swing Over Table Ø 15.7" (400 mm)
Distance Between Centers 24.8" (630 mm)
Optional Wheel Surface Speed 11,800 SFPM (60 m/s)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed 8,860 (45) SFPM (m/s)

Swing Over Table Ø 15.7" (400 mm)
Distance Between Centers 39.4" (1,000 mm)
Wheel Surface Speed 660 lb (300 kg)
Grinding Diameter 8,860 SFPM (45 m/s)
Optional Wheel Surface Speed 11,800 SFPM (60 m/s)

Swing Over Table Ø 7.9" (200 mm)
Distance Between Centers 320mm
Maximum Load Between Centers 11 lb (5 kg)
Wheel Surface Speed 8,860 SFPM (45 m/s)
Grinding Diameter 0 ～φ80mm

Swing Over Table Ø 7.9" (200 mm)
Distance Between Centers 11.0" (280 mm)
Maximum Load Between Centers 11 lb (5 kg)
Wheel Surface Speed 8,860 SFPM (45 m/s)
Grinding Diameter 0 ～φ80mm

GC20Mi-35
Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 13.8" (350 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed φ350 wheel: 4.7 (120) SFPM (m/s)

GC20Mi-63
Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 24.8" (630 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed φ350 wheel: 4.7 (120) SFPM (m/s)

GC32M-63
Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 24.8" (630 mm)
Grinding Diameter (Max) 7.8 (200) in (mm)
Wheel Surface Speed 6.2 (160) SFPM (m/s)

GC32M-200
Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 78.7" (2,000 mm)
Grinding Diameter (Max) 13.7 (350) in (mm)
Wheel Surface Speed 23,500 (120) SFPM (m/s)

X-axis 800mm
Y-axis 800mm
Z-axis 880mm
Table dimensions（pallet dimensions) 550mm x 500mm

X-axis 900mm
Y-axis 800mm
Z-axis 880mm
Table dimensions（pallet dimensions) 550mm x 500mm

X-axis 900mm
Y-axis 800mm
Z-axis 880mm
Table dimensions（pallet dimensions) 550mm x 500mm

X-axis 25.2” (640)
Y-axis 24” (610)
Z-axis 26.8” (680)
B-axis Travel .001
Pallet Size 19.7” x 19.7” (500 x 500)

Strokes X, Y & Z axes 800 X 550 X 550
Table size / Pallet size 500 x 630 (2)

X-axis 1,050mm
Y-axis 900mm
Z-axis 1,050mm
Table dimensions (pallet dimensions) 630mm

X-axis 1,450mm
Y-axis 1,250mm
Z-axis 1,550mm
Table dimensions (pallet dimensions) 800mm

X-axis 1,600mm
Y-axis 1,400mm
Z-axis 1,850mm
Table dimensions (pallet dimensions) 800mm × 1,000mm

X-axis 2,400mm
Y-axis 1,500mm
Z-axis 1,850mm
Table dimensions (pallet dimensions) 1,250mm
