Travel in X-axis 6200 mm
Travel in Y-axis 1000 mm
Travel in Z-axis (ISO 40 / BT 40 / HSK-A63) 980 mm
Travel in Z-axis (HSK-A100) 950 mm
Table Size: 6470 mm x 1050 mm
Travel in X-axis 5200 mm
Travel in Y-axis 1000 mm
Travel in Z-axis (ISO 40 / BT 40 / HSK-A63) 980 mm
Travel in Z-axis (HSK-A100) 950 mm
Table Size: 5420 mm x 1050 mm
Travel in X-axis 4200 mm
Travel in Y-axis 1000 mm
Travel in Z-axis (ISO 40 / BT 40 / HSK-A63) 980 mm
Travel in Z-axis (HSK-A100) 950 mm
Table Size: 4500 mm x 1050 mm
Travel in X-axis 3200 mm
Travel in Y-axis 1000 mm
Travel in Z-axis (ISO 40 / BT 40 / HSK-A63) 950 mm
Travel in Z-axis (HSK-A100) 920 mm
Table Size: 3500 mm x 1050 mm
Travel in X-axis 2000 mm
Travel in Y-axis 800 mm
Travel in Z-axis 750 mm
Table Size: 2400 mm x 950 mm
Travel in X - axis 750 + 50 mm
Travel in Y - axis 610 mm
Travel in Z - axis 500 mm
Table dimensions length / width - 900 / 650 mm
Travel in X - axis 1200 + 50 mm
Travel in Y - axis 610 mm
Travel in Z - axis 500 mm
Table dimensions length / width - 1340 / 650 mm
Travel in X 350mm
Travel in Y 250mm
Travel in Z 300mm
Clamping Area 520x300mm
Max. table load 100kg
EMCOMILL 1800
Travel in X-axis 1800mm
Travel in Y-axis 610mm
Travel in Z-axis 500mm
Table dimensions length / width 2000 / 650mm
Max. table load 2000kg
EMCOMILL 1200
Travel in X-axis 1200mm
Travel in Y-axis 610mm
Travel in Z-axis 500mm
Table dimensions length / width 1340 / 650mm
Max. table load 1500kg
MECMILL
Longitudinal axis travel 6000 - 16000mm
Cross axis travel 1600mm
Vertical axis travel 3500 - 4000mm
MECMILL PLUS
Longitudinal axis travel 6000 - 16000mm
Cross axis travel 1600 - 1850mm
Vertical axis travel 4000 - 5000mm
X (transverse axis) 1800mm
Y (horizontal axis) 2150mm
Z (vertical axis) 1250mm
X (transverse axis) 1500mm
Y (horizontal axis) 1500mm
Z (vertical axis) 1100mm
Travel in X 750 + 50mm
Travel in Y 61mm
Travel in Z 500mm
Clamping area 750x600mm
Max. workpiece weight (equally distributed) 400 kg
Travel in X 750+50mm
Travel in Y 610mm
Corsa asse Z 500mm
Swivel range B-axis +/-100°
Range of rotation C-axis (rotary table) 0 - 360°
Clamping Area 750x600mm
Max. workpiece weight with counter bearing 300kg
Max permissible workpiece weight with counter bearing 500kg
Travel in X 500+50mm
Travel in Y 460mm
Corsa asse Z 450mm
Swivel range B-axis +/-100°
Range of rotation C-axis (rotary table) 0 - 360°
Clamping Area 630x500mm
Max. workpiece weight with counter bearing 200kg
Max permissible workpiece weight with counter bearing 400kg
Stroke X-axis 915mm
Stroke Z-axis 3100 / 4100 / 5100 / 6100mm
Stroke Y-axis +/- 300mm
Swing diameter over the bed 1050mm
Max. turning diameter 1000mm
Distance between spindle and center (MK 6) 3200 / 4200 / 5200 / 6200mm
X1-axis 780 (+760/-20)mm
Y-axis 420mm
Z1-axis 1500 / 2200 / 3100mm
Swing over bed 800mm (without tool turret)
Max. turning diameter 720mm (with milling spindle)
Length between spindle and centre 1700 / 2400 / 3300mm
Travel X1 / X2 / X4 405 / 210 / 210mm
Travel Z1 / Z2 / Z4 1040 / 850 / 800mm
Travel Y1 / Y2 / Y4 220 / 100 / 100mm
Swing over bed 500mm
Distance between spindle noses 1300mm
Maximum turning diameter 500mm
Travel path X1 / X2 530 / 210mm
Traverse path Z1 / Z2 1215 / 1205mm
Traverse path Y 240mm
Traverse path counter spindle Z3 1250mm
Swing over bed 500mm
Distance between spindle noses 1500mm
Maximum turning diameter 500 mm
Travel X1 / X2 405 / 210mm
Traverse path Z1 / Z2 1040 / 1050mm
Traverse path Y1 / Y2 220 / 100mm
Traverse path counter spindle Z3 1045mm
Swing over bed 500mm
Distance between spindle noses 1300mm
Maximum turning diameter 500mm
Travel in X1 with B-axis / X2 +540/-10 (340) / 300mm
Travel in Z1 with B-axis / with tool turret / Z2 1300/1900 (1340/1940) / 1340/1940mm
Counter spindle travel 1360/1960mm
Swing over bed 720mm
Distance between spindle noses 1700 / 2300mm
Max. turning diameter 710mm
Travel in X1 with B-axis / X2 +540/-10 (340) / 300mm
Travel in Z1 with B-axis / with tool turret / Z2 1300/1900 (1340/1940) / 1340/1940mm
Counter spindle travel 1360/1960mm
Swing over bed 720mm
Distance between spindle noses 1700 / 2300mm
Max. turning diameter 710mm
Traverse path X1 / X2 (HT65 DUOTURN) 260 / 210mm
Traverse path X1 / X2 / X3 (HT65 TRIPLETURN) 260 / 260 / 210mm
Traverse path Z1 / Z2 (HT65-1000 DUOTURN) 800 / 800mm
Traverse path Z1 / Z2 (HT65-1300 DUOTURN) 1050 / 1050mm
Traverse path Z1 / Z2 / Z3 (HT65 TRIPLETURN) 450 (440) / 450 (440) / 1050mm
Swing over bed 660mm
Swing over cross slide 540mm
Distance between spindle noses 1050 / 1300mm
Slide travel in X / X2 160 / 150mm
Slide travel in Z / Z2 / Z3 510 / 510 / 510mm
Travel in Y +40 / -30mm
Swing over bed Ø 430mm
Swing over cross slide Ø 300mm
Distance from main spindle to counter spindle 720mm
